More autonomy, more connectivity and the latest Bosch technology featured in an accessible package. From off-road commuting to your local trails, the Aspect is all about versatility and fun.
Frame Alloy XS-XL=29", 6061 Alloy custom butted tubingSide extraction batteryUDH Interface, 12x148mm with 52mm Chainline
Travel 120mm
Fork SR Suntour XCR34X LOR Air, Tapered 120mm Travel, 15x110 bolt Axle, Remote Lock Out
Remote System SR Suntour Remote
Drive Unit EU: 25kmhBosch Performance Line CX (BDU384Y)
Battery PowerTube 800Wh
Display Bosch System Controller Kiox 300Mini Remote
Charger 4A Charger
Rear Derailleur Shimano Deore RD-M6100 SGSShadow Plus, 12 Speed
Shifters Shimano Deore Trigger SL-M6100RC
Crankset FSA CK-220165mm
Chainring FSA 36T w/Chain Guard
Chain KMC e12S
Cassette Shimano CS-M6100, 10-51
Brakes Shimano BR-MT420 Disc Brakes
Rotor Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 180mm
Handlebar Syncros 3.0 720mm, 31.8mm, 9°, 12mm riseSyncros Comfort lock-on grips
H'stem Syncros AM2.0, 6061 Alloy31.8mm, 0°
Seatpost Syncros M3.0, 31.6mm350mm
Seat Syncros Tofino E 2.0
Headset Acros, 1.5"- 1.5"semi integ. OD 50/61mm, ID 44/55mm
Hub (Front) Formula CL-811, 15x110mm
Hub (Rear) Formula MSC-148S, 148x12mm
Spokes Black Spokes
Rims Cross X19, 32H, 30mm, Pin Joint
Front Tire Kenda Booster 29x2.6", 30TPI
Rear Tire Kenda Booster 29x2.6", 30TPI
Lights Bosch Light Cable pre-installed F&R
Approx weight in KG 26.7
Approx weight in LBS 58.86
Max. System Weight 130kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Please note that bike specifications are subject to change without prior notice.
